Recently planning to get a small steel gun, the platform still wants to use 3A, 1700X is already in hand, the motherboard can only Biostar X370GTN or B350GTN can be selected, memory, cooling what to say, are ready-made, and other on-demand purchase Yes. There are only two things that give me a headache. One is the chassis and one is the graphics card.
Let's talk about the chassis first. Is it the limit of space? Or is it part of the compromise? If you compress the space, not only do you have to replace the power supply, but the video card is also very difficult to choose. Touched my hands on the two graphics cards, a Asus STRIX RX480 O8G GAMING, a GALAXY GAMER GTX1070 all exceeded 30cm......
The election didn't really care about the chassis, but it was full of interest in the RX580 that was just listed. In other words, playing hardware is addictive...especially when it comes to upgrading new hardware, you want to get started...and the previous hardware is new. , so you can not lose a lot of money to lose hands ... and sometimes even before and after the special deal, it is even more indispensable to replace it ... or even full of suspicion ... if the memory and solid state, spent a year to change hands or even make money ... ...
People are like this, the heart is long grass, not pull, especially see their own two graphics cards into the packaging which can almost "fill the new", so I think you want to decide to enter a RX580, more graphics card slowly shot Which one is counted?
Some people ask why RX580 is not RX570? Because ... I used the 2K screen ... ... sometimes play play watch what, RX570 open effects may still be a bit ...
Well, if I want to go to the ITX chassis, I have to choose the smallest RX580... (I... I actually remember that the chassis had to do something... no matter... first choose the graphics card).
Often I am very happy at this time, in general, in addition to the sapphire RX580 8G ultra-platinum, I have no choice, because the RX580 ultra-high-frequency RX580 is the smallest, the smallest RX580 frequency. So... I welcomed this Sapphire RX 580 8G Ultra Platinum. Why don't you buy a more limited version of Ultra Platinum? The reason is simple. The regular version of the RX580 Ultra Platinum is 250 yuan cheaper, and I also don't like the "Blue Flame Gas Cooker" which is built by the fan with the light....
Say back to the chassis selection problem, Yin Xin's crow may be my last choice, just can hold RX580 super platinum, and then is to tangled the choice of SFX power, and the Italian B350GTN is also not available ...
According to my observations, most of the RX400 series are out of stock after the RX500 series takes office. Even if the sales estimate is an inventory product, manufacturers should no longer mobilize production capacity to produce the RX400, and the appearance of the RX500 series of various manufacturers is compared with the RX400 series. The change is not large. Through these phenomena, I can conclude that the RX500 is just a small change to the RX400, and the performance difference does not bring about qualitative changes.
Anyway, first on the graphics card!
Sapphire RX580 8G D5 Super Platinum graphics card 1949 yuan 1340-1411MHz/8000MHz 8GB/256bit GDDR5 DX12 independent game graphics Jingdong direct link Pulled so much useful and useless above, the following began to enter the box out of the box, after all, out of the box cool over that ... ...
Well, let me start with the box...
Sapphire this time changed the main color to blue-purple, and the RX400 series is still different, but there is no essential difference.
What does the video card box look like? Unpacking! â—¢
The third oldest kind in the box, graphics card, manual, CD-ROM... Oh, I just want to see when the CD can be replaced with a U-disk... Now there are several machines with optical drives.
The appearance of the RX580 Platinum Platinum Exterior also said, but only some details of the changes, but personally think that more than a RX480 Platinum lost texture
Do not say this RX480, RX470, RX570 are used this backplane â—¢
Dual HDMI, Dual DP, One DVI, Bezel with "S" Design
If I remember correctly, the RX480 Ultra Platinum should be the tail 8PIN power supply
The power supply has been moved to the side, 8PIN+6PIN, a hole has been dug on the side, and the heat pipe has been exposed.
The side of the sapphire English LOGO glow retained, the default Blu-ray, but you can go to the software settings, set up, the color will be set until the next set â—¢
Dual BIOS design, game mode on the left and silent mode on the right
The fan is easy to disassemble, just remove the screws and it is easy to clean. The noise control of these two fans is still OK.
The appearance of so many shows, this card does not look too much from the appearance of tricks, but the work is still good, especially the backplane, should be considered a few of the most sense of design, the other, it touches can be circled Point, if you like styling friends, this graphics card should not be your dish, but for me this has special requirements, or a good choice â—¢
Demolition and demolition is always a favorite aspect. In fact, I can't really understand if I break it apart, but I still look at it for you. I understand it is good or bad. I’ll talk about it and I’ll learn it, every day. Look at the soft paper and open up what the black gold capacitor black diamond inductor blows, it's not a problem.
After studying it, first remove the screws from the four screws.
Pay attention to the observation, remove the screws around, and the shell can be removed.
The heat sink is almost fully covered, with four heat pipes, and it's really strong.
Shell removal is very simple, easy to deep clean, in fact, the beginning of the demolition of the video card is watching, this graphics card actually does not have a warranty sticker ... that now manufacturers are enlightened, casually demolished ... ... did not expect, in fact, is a blue treasure for a routine, warranty stickers actually Is... (pictured), screw capped with paint
After unscrewing it is irreversible...â—¢
Hee hee... Since it's broken down, it's all right now. Anyway, my graphics card has never been broken...
Remove the 4 screws around the core, and the machine can remove all the heat.
However, the backplane is still firmly on the PCB board, let's think it is the three small screws to stabilize it, too lazy to tear down. Let's take a look at the front of the PCB.
Positive
Silicon grease wipe clean
BIOS dial-up
PS Next I guess, I guess, I guess Guess
BIOS chip? â—¢
This phase power supply is to? Memory?
This is memory, I know, Hynix's cargo
This should be the core power supply phase, 6 +1? The top one is also memory? â—¢
This should be the power chip, right? â—¢
GPU, Made in Taiwan, can you change to MADE IN CHIAN? â—¢
OK, nothing can be seen, ready to put it back, turned a bit on this point, go back to the point of entry, or go back to install no silicone grease used, wipe grease, ready to install back
On the machine
Yes, for this article is not purely out of the box, I still do not bother to first look at the machine test to see you, the following into the running minutes!
Section III Performance Test
Let's take a look at my test platform first. Actually, I have a 7700K platform, a set of Ruilong platform. On the game, many new games are not bad, but some old games are not as good as 7700K, and some are even finished. burst! In the previous post, I also said this issue, specifically showing the "one-core" online game represented by "World of Warcraft" on the 1700X.
Because in the planning of another "big thing" 7700K temporarily not use, so only use Ruilong platform to test for you, but this can also give you a friend of Ruilong to make a show, anyway, this card is also inserted in the My sharp dragon cannon. However, the performance of the 7700K platform RX580 is definitely better. You can make it up yourself. I'm not saying that Ruilong is worse than the 7700K. The performance is definitely a few 7700Ks thrown by the Ruilong 1700X, but in terms of playing games, the 7700K is not only Good enough for use, and more widely applicable...
Look at the RX580 Platinum parameters, in addition to the open frequency, the basic and RX480 is no different.
75.9% of body physique feels ok
Each manufacturer's graphics card has debugging tools, as does sapphire.
The sapphire graphics tool is called Sapphire Trixxx and can be downloaded from the official website.
Main interface
There is a Power button below, click this, and then APPLE, you can overclock to 1425 in one click.
In fact, the biggest use of this software is color correction.
Click on the flashlight in the lower left corner to change the color, breathing, circulation, temperature, monochrome, brightness can also be adjusted, you can also turn off the light â—¢
It is worth to say here, before starting, see the official nominal 1340-1411MHz, I think it is a BIOS switch, or similar to this one-button overclocking mode to change the frequency, in fact, this trick is directly to the RX580 Platinum Graphics Is the frequency of 1411, a key official up to 1425, and the gap between the limited edition becomes smaller (in fact, I think, the limited edition is a different light, limited edition to the frequency, I can also come to the ordinary version, maybe also Can brush a limited edition BIOS...), so say that the ordinary version is more cost-effective than the limited edition.
The following is the first time that the national hero Lu masters run points, 18W1 feel that the previous generation of cards looks like they can also come to this score.
Then comes 3DMark's running delivery
Due to space limitations, the actual measurement of each of my games here is not one by one. Here's a summary of them for your reference:
Through the form we can see, RX580 ultra-platinum in 2K resolution, the overall performance is to meet the smooth needs of the game. It is worth mentioning here is still playing 12 years of World of Warcraft, I found that after the game is updated, under the 1700X platform, the frame rate dropped a lot, slightly abnormal, after reinstalling the driver feeling, should be the game Problems with A card support.
Show below the power consumption of RX580 Ultra Platinum
The first test is the performance without pulling the power limit.
The temperature was found to be stable at 76°C in Furmark roast chicken, but after baking for a while, the frequency dropped to 1260+. It was estimated that it was hit by a temperature wall or a power-consumption wall. This caused me to think... What is the difference between RX480 ... but when playing the game, through the software monitoring, did not find the situation of the downclock, may be Furmark too fierce it
Via piracy ship LINK software display, power input 314W, 12V output 262W
Measured around 300W
CPU standby power is only 10W? â—¢
Then "power limit" pulls up 50%.
After pulling the power limit, it can be stabilized at the frequency of 1411. It's worth talking about here, but the temperature is also increased to 80 degrees Celsius. The fan is full of sound, but it can't be called noise, and the control is pretty good.
It can be seen that after pulling up the limit, the power has increased by a certain margin, around 80W.
Then I do an immature calculation, increase the 50% power limit is 80W, then the overall power consumption of the graphics card should be?
YX=80W
(YX)/X=50%
Then X = 160W, 380W multiplied by 92% efficiency minus (X + 80W), then it is drawn that the power consumption of other things should be around 110W? Motherboard + 7 fans + 2 memory + 1 water-cooled + CPU (10W) should look similar. â—¢
However, there is a 20W gap between the input power of this LINK calculation and the apparent difference.
The CPU is still only 10W in standby mode
After upgrading the technology, the "Polaris" core can run at a higher frequency, and the RX500 has naturally become a product that replaces the RX400 series to reactivate the market. If it is necessary to say "crown toothpaste" or "transform vest", there is nothing wrong with it. But fortunately, it is good. Before and after the two generations of time is not a long time, and the price did not increase, and the old models have also been discontinued, so this "replacement" is actually Polaris graphics card in the mid-term "change", no problem.
So the question is, RX580 ultra-platinum, or is it worthwhile to buy RX580?
This depends on how you look at this issue. First of all, if you are upgrading RX580 from RX480, it is completely unnecessary. The gap between the two is very small, about 5-10%. However, if it is an inter-generational upgrade, or a new video card, I think if you like AMD, it is also good to start. So why not start with the 1060 or the old RX480? The first point, GTX1060 and RX580 compared to cost-effective, so like N card users, naturally choose GTX1060 is the last word. As for the RX480, it was said before, and it has been discontinued. If you can still buy stocks, and compared with the same model of the RX580, the price is about 10-20% lower, or you can buy it.
OK, today's unpacking and dismantling the machine test, it is here, very happy to share with you, this time because of energy problems, there is no test on what overclocking, I'm very sorry. I have to go and continue to plan my 3A steel cannon....I'm living a real “full†day...sleeping? nonexistent……
Thank you for watching...
